Delock – 87586 – USB 2.0 adapter to 2 x serial RS-422/485

Brand:
Delock

76,35 €

incl. 19% VAT plus shipping costs

With this adapter from Delock, up to two serial devices can be connected via a USB type-A port. Specification Connectors: 1 x USB 2.0 Type-B female > 2 x serial RS-422/485 DB9 connector Chipset: FT2232HL, SP3078EE 2 x DIP switches: RS-422/485 mode…

Show article information
In stock
When you purchase this item you will receive. 76 Points
Bulk PriceQuantity (from)Quantity (to)
76,35 € 1 19
73,17 € 20 49
72,54 € 50 199
71,90 € 200 ∞
Delivery time: 3-5 Workdays
Add to quote request
SKU 361251
EAN 4043619875863
MPN 87586
Categories ,
Tags , ,

With this adapter from Delock, up to two serial devices can be connected via a USB type-A port.

Specification

  • Connectors:
  • 1 x USB 2.0 Type-B female >
  • 2 x serial RS-422/485 DB9 connector
  • Chipset: FT2232HL, SP3078EE
  • 2 x DIP switches: RS-422/485 mode setting
  • Internal pin connectors: jumpers switch terminators on / off
  • Serial connector with nuts
  • Data transfer rate up to 1 Mbps
  • LEDs to indicate TxD / RxD activity
  • Automatic detection and switching between RS-422 and RS-485
  • ±15 kV ESD protection on all signal pins
  • Wall bracket integrated in the housing
  • Current consumption:
  • Operation: ≤ 141 mA / 705 mW
  • Standby: approx. 89 mA / 445 mW
  • Additional I/O and IRQ are not required
  • Operating temperature: 0 °C ~ 70 °C
  • Dimensions (LxWxH): approx. 107 x 65 x 23 mm

System requirements

  • Linux kernel 2.6 or higher
  • Windows Server 2012/Server 2012 R2/Server 2016
  • Windows Vista/Vista-64/7/7-64/8.1/8.1-64/10/10-64/11
  • PC or notebook with a free USB type-A port

Package contents

  • USB 2.0 to 2 x Serial RS-422/485 adapter
  • USB 2.0 cable
  • 4 x jumpers
  • Driver CD
  • Instruction manual

Packaging

  • Retail Box
Weight 0,3 kg
Dimensions 20 × 15 × 10 cm
Professional use

Yes
Produkttyp

Adapter
Color

black
Connection A

RS485
Adapter type

RS232
Connection B

RS422

Product safety

Manufacturer information

Tragant Handels- und Beteiligungs GmbH
Beeskowdamm 13/15
14167 Berlin
DE - Deutschland

E-Mail: info@tragant.de

Person responsible for the EU

Tragant Handels- und Beteiligungs GmbH
Beeskowdamm 13/15
14167 Berlin
DE - Deutschland

E-Mail: info@tragant.de

Brand:
Delock

With a mixture of novelties, proven bestsellers and niche products, Delock offers an attractive and continuously expanding product selection which is adjusted to the technical developments of the IT market. Since the registration of the brand in 2001, in a continuous growth process Delock has achieved to establish itself step by step as a trend-setting...
