The QuPanel 5G/LTE Directional MIMO 2×2 High Gain antenna is mainly intended for 5G and 4G LTE, but is also compatible with 3G and 2G. The antenna improves the signal in rural/suburban areas and in places where the mobile signal is weak. This antenna is expected to be installed on buildings (on a mast or on the wall). Due to the very wide working frequency range, the antenna is a universal client for the 5G bands n77, n78 and LTE bands such as LTE700 / 800 / 1800 / 1900 / 2100 / 2300 / 2600 / 3400 / 3800. It is compatible with Teltonika: RUT240, RUT900, RUT950, RUT955, RUTX09, RUTX11 and other MIMO 2×2 5G / LTE / 3G / 2G modems and routers.

5G/LTE antenna specifications
– Frequency: 0.694-0.96 GHz; 1.7 – 2.2 GHz; 2.2 – 2.7 GHz; 3.3-3.8 GHz
– Supported LTE bands: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 22, 23, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 48, 49, 52, 53, 59, 62, 65, 66, 67, 68, 69, 85, n78, n80, n81, n82, n83, n84, n86, n89, n90, n95
– Gain: 0.694 – 0.96 GHz : 7 dBi; 1.7 – 2.2 GHz : 7 dBi; 2.2 – 2.7 GHz : 7.5 dBi; 3.3 – 3.8 GHz : 5.5 dBi
– VSWR: <1.70, maximum <2.00
– Beam width: 70°/70° ±15°
– Polarisation: Dual polarised X-pole
– Impedance: 50 Ω

Mechanical specifications
– Materials: ABS, aluminium, PTFE, glass fibres
– Protection class: IP67
– Dimensions: 272 x 276 x 96 mm (10.71 x 10.87 x 3.78 inches)
– Weight: 1.8 kg (3.97 lbs)
– Operating temperature: From -40°C to 80°C (from -40°F to 176°F)
– Connector type: Integrated Nf connectors
