RUTX08 000000 - RUTX08 - Industrial VPN Router

Teltonika RUTX08 - Industrial VPN Router

This robust industrial router is equipped with 4x Gigabit Ethernet ports, quad-core CPU and 256 MB of RAM. These powerful specifications combined with core RutOS software features such as multiple VPN services, advanced firewall and RMS support makes this device a superb industrial performer where no cellular or Wi-Fi connectivity is required.

Reliable

• Connection watchdog

• RMS ready

• Industrial grade hardware


Robust

• Durable aluminum housing

• Wide voltage range (9 to 50 V)

• External temperature range (-40 to +75 °C)


Secure

• Multiple VPN options

• Advanced firewall functionality

• Various encryption protocols supported

Standard package contains

• RUTX08 router
• EU PSU
• Ethernet cable (1.5 m)
• QSG (quick start guide)
• Packaging box

Hardware

• CPU: Quad-Core ARM Cortex A7 717 MHz CPU

• Memory: 256 MBytes Flash, 256 MBytes DDR3 RAM

• Ethernet: 4x 1 Gbit Ethernet ports: 1x WAN (configurable as LAN), 3x LAN ports

• Power supply: 9 - 50 V DC, 4-pin DC connector

• Connectors: 1x 4-pin DC, 4x Ethernet

• Status LEDs: 1x Power,

• Operating temperature: -40 °C to 75 °C

• Housing: Full aluminium with grounding terminal

• Dimensions: 115 mm x 95 mm x 44 mm

• Weight: 185 g

Software

• Operating system: RutOS (OpenWrt based Linux OS)

• Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DHCP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, ARP, PPPoE, UPNP, SSH, Telnet

• Networking features: NAT, Static/Dynamic routing, Firewall, OpenVPN, IPSec, H.232 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets

• Unique networking features: VLAN, WEB filter, load balancing

• Connection monitoring: Ping Reboot, Periodic Reboot, LCP and ICMP for link inspection

• Authetication: Pre-shared key, digital certificates, X.509 certificates

• Keep settings: Update FW without loosing current configuration

• Monitoring & management: WEB UI, SSH, SMS, SNMP, JSON-RPC, FOTA, RMS

• Supported languages: Busybox shell, Lua, C, C++

• Development tools: SDK package with build environment provided
