PSE-1000GU - 802.3at/af Gigabit PoE Adapter

Deliverytime: 75 - 77 working days (Mo-Fr) *
30,09 EUR
Product Description

ALFA Network PSE-1000GU 802.3at/af Gigabit PoE Adapter

Features

  • Gigabit Ethernet speeds
  • Up to 30 W power
  • Desktop, shelf and easy wall mounting
  • Use for Access Points, VoIP and IP cameras

  • Standards: IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3af, IEEE 802.3at
  • Ethernet data rate: 10/100/1000 Mbps
  • Dimensions: 136 x 65 x 38.5 mm
  • LED: Power LED / PoE LED
  • Weight: 168 g
  • Pin assignment and polarity: 1/2 (+), 3/6 (-)
  • Reliability: MTBF: 50,000 hrs (at) 25°C
  • Input power:
    • Voltage: 90 to 264 V ac
    • Current: 750 mA
  • Frequency: 47 ~ 63 Hz
  • Temperature:
    • Operation: -10°C ~ 40°C
    • Storage: -20°C ~ 85°C
  • Output power: 48 V dc/600 mA, 30 Watt
  • Humidity:
    • Operation: 5 ~ 90%
    • Storage: 5 ~ 90%
  • Certificated: UL/CUL, CB, GS/LVD, FCC, CE

Downloads
File type: pdf | File size: 412.93KB
